LED Lowbay Genbay 02

The Genbay 02 Low Bay is a heavy-duty, modular linear LED high bay luminaire designed for high-ceiling industrial and commercial applications. Available in power outputs ranging from 100W to 600W, it features field-selectable power and Colour temperature controls (on 1.2m models), wide voltage support, and smart control integration. Built with modular aluminum construction, it delivers high luminous efficiency up to 150 Lm/W, making it ideal for warehouses, factories, workshops, gymnasiums, and supermarkets.
Key Features
• Field-Selectable Power & CCT: Features integrated slide switches for on-site power adjustment (20\%, 40%, 60%, 80%, 100% and Colour Temperature selection 3000K, 4000K, 5000K.
• Modular Architectural Structure: Flexible construction utilizing 2-module or 4-module configurations across 4 length options 0.4 m, 0.6m, 0.8m, and 1.2 m for simplified maintenance.
• Integrated Plug-in Hardware: Supports seamless integration with 2-in-1 motion sensors, photo sensors, infrared sensors, and wireless control nodes.
• Advanced Wireless Controls: Fully compatible with Zigbee, Bluetooth (mobile phone direct connect), PLC, and Wi-Fi system networks.
• Multiple Optical Options: Choice of clear or frosted lenses with tailored beam distribution angles (30* 60, 78, or 120
• Versatile Mounting Systems: Supports Wire/Chain Hanging, Direct Ceiling Mount, or Suspended Threaded Rod installations.
Technical Specifications
Optical & Photometric
• Light Source: High-efficiency, LM-80 approved 2835 SMD LEDs
• Luminous Efficacy: Standard 130 Lm/W to 150 Lm/W (higher efficiency options available)
• Beam Angle Options: 30°x 60°, 78°, or 120°
• Colour Temperature (CCT): Standard 3000K, 4000K, 5000K, 5700 K, 6500K
• Colour Rendering Index (CRI): 70 / 80
• Lens Options: Clear PC or Frosted PC Lens
• Driver Brands: Meanwell HLG, Sosen, or equivalent branded LED drivers
• Dimming Support: 0–10V, DALI, PWM, and Timing Dimming protocols
Mechanical & Environmental
• Housing Material: Heavy-duty 6063 Extruded Aluminum Housing & Heat Sink + Polycarbonate (PC) Lens
• Protection Class: IP20
• Operating Temperature: -40°C to +45°
